Product details
| Power | AC 110V, Single Phase 50/60Hz 1.5KW Max. 220VAC is available upon request |
Structure  | SS316 case for anti-corrosive processing The crucible furnace has a heating chamber of 4.7″ D x 8″ H, (120 mm ID x 200 mm H) The separated temperature controller for remote operation The temperature controller is separated from the furnace for safe operation |
Processing Tube and flange  | The quartz tube with one end closed and a flange and valve is inserted into the heating chamber for processing under a vacuum Quartz tube dimension: 100mm OD x 94 mm ID x 250 mmL One flange with 1/4″ gas inlet and needle valve, KF 16 port ( to install a vacuum gauge), and KF 25 port ( to connect to a vacuum pump, as well as KF25 Vacuum Right-Angle Valve are included Optional: KF-16 could be used on the Anti-Corrosive Digital Vacuum and bellow tube can be order by click the picture below: Vaccun level: 10-2 torr by mechanical pump and 10-5 torr vy turbo pump    |
| Max. Temperature | Max. 1100°C for short time <1hour Continuous working temperature: <1000°C |
| Max. Heating Rate | 20 °C /min Max. |
Temperature controller | Two digital temperature controllers is built a separate box with +/- 1ºC accuracy One controller and T/C is for controlling PID automatic control and auto-tune function. 30 programmable segments for precise process Built-in protection for over-heated and broken Thermal couple. Another one is for monitoring furnace running and cut-off power if the furnace overheated Two Omega K-type thermal couples included RS485 port installed for PC operation |
Rotating blade fixture option | We can add an air-tight rotating blade fixture on the top of the flange to allow you to stir molten at the adjustable speed ( extra cost will be applied) Rotation Speed: 0 – 300 rpm variable via a digital speed controller Vertical moving distance: 5 – 200 mm manually adjustable |
Dimension | Control Unit: 340mm L x 300mm W x 145mm H Furnace: 350mm L x 265mm W x 390mm H |
| Net Weight | 15 kg |
| Shipping package size | 45″ x 28″ x 35″ (after crating) |
| Shipping weight | 260 lbs |
| Warranty | One-year limited warranty (Consumable parts are not covered by the warranty) |
| Certificate | CE Certified NRTL Certification is available upon request, additional charges will apply |
| Operation Instructions | https://youtu.be/gFhv12_CTuA |
