Product details
SPECIFICATIONS
| Power Requirements | Input: 208V-240V 50/60Hz Power: 180W 110VAC is available via a 1500W transformer [both the vibration sieving system and control box]. |
| Motor Speed | 1420 rpm |
| Dimension (W×D×H) | Sieve System: 360 × 300 × 740 (mm) Ultrasonic Power: 350 × 300 × 200 (mm) Sieve: I.D. 200⌀ × 50 H (mm) Three Sieves are included with 100, 200, and 450 mesh (equivalent to 149, 74, 32 microns) |
| Max. Load | 1kg |
| Sonicator | Sonication is used for fine particles separation. Frequency: 38 kHz Max Mesh size: 450（32 microns) |
| Work Mode | Continuous or pulsed |
| Shipping Weight & Dimensions | 150 lbs40″ x 30″ x 35″ |
| Operation Manual & Video | https://youtu.be/1gjxPtIBvGs https://youtu.be/0zFuPn-JVN0 |
| Application Notes | Do not turn on the ultrasonic generator without a sieve. Doing so may cause overcurrent or damage on the sieve frame and the converter.When filtering the conductive material, separate the ultrasonic generator from the sieve with an extended HF cable. The extended connection keeps the conductive material from getting into the ultrasonic generator, causing a short circuit. |
| Warranty | One-year limited warranty with lifetime support |
| Accessory | ||
| Item No. | Descriptions | Qty |
| MSK-SYU-3 | Vibration Sieving System | 1 unit |
| SYU-Sieve | (Dia 200mm*50mm H) Sieve， three pieces in mesh 100, 200, and 450. | 1 set |
| SYU-Generator | Ultrasonic generator box | 1 set |
