Lab Scale High-Efficiency Cyclone for Jet Mill - BPM-CL
Lab Scale High-Efficiency Cyclone for Jet Mill - BPM-CL - Image 2
Lab Scale High-Efficiency Cyclone for Jet Mill - BPM-CL - Image 3
,

Lab Scale High-Efficiency Cyclone for Jet Mill – BPM-CL

In stock

$3,598.00

BPM-CL is a lab-scale powder cyclone used with the MTI Jet Mill and offers optimum recovery of sub-micron fines. Undersize sieve fractions are directed through an anti-static vacuum hose through the cyclone and collected in a threaded glass receiving bottle. Material contact parts are constructed of stainless steel or glass. Support stand allows for stand-alone operation, or the unit can be mounted to the base of an Air Jet Sieve.

  • Estimated delivery time 14-30 days
  • 18 months warranty at Genuine Warranty Center.
  • Whats in the box: charging cable and block
Buy now
<span class="ts-tooltip button-tooltip" data-title="Add to compare">Compare</span>
SKU: lab-scale-high-efficiency-cyclone-for-jet-mill-bpm-cl

Product details

Specification

FeaturesThe estimated collection efficiency: 85% – 90%Can operate as a stand-alone unit or when mounted to a Jet MillAssemble by using tri-clamp connection
Item Included1 x Collection Bottle(500ml)1 x Stainless Steel Cyclone1 x Filter(10um mesh) for > 0.3um powder collection.
Dimension
 Net Weight~57lb (26kg)
Note:Large-size cyclones are available upon request. (Pic. 1)It is designed for an MTI jet mill (Pic. 2)A customized cyclone collector equipped with a 90mL collection tank and two CF50 ports is available upon request. (Pic.3)Pic.1 Pic.2Pic.3

Pic.1 Pic.2Pic.3
Particle Size DistributionMaterial: Graphite
Original Powder Size: D50=20um
One-time Jet-milling Powder Size in Collection Bottle: D50=5.4um
One-time Jet-milling Powder Size in Filter: D50=1.94um
