Programmable & Automatic High-Energy Impact Grinder and Mill

Programmable & Automatic High-Energy Impact Grinder and Mill – VGM-50-AM

In stock

VGM-50-AM is a programmable and automatic vertical impact grinder and mill for crushing, grinding, and milling sintered ceramic samples up to 0.1 microns. It can adapt various grinding jars from 1.5 ml to 50 ml and provides a high-energy impact force with an amplitude of 16 mm at a frequency of 3000 times/ minute. Milling time, rest cooling time, and speed are programmable via a separate touchscreen box. This device can be used inside an argon gas glovebox and can achieve automatic ball milling via a robotic arm.

Estimated delivery time 14-30 days
18 months warranty at Genuine Warranty Center.
Whats in the box: charging cable and block

SKU: programmable-automatic-high-energy-impact-grinder-and-mill-vgm-50-am

Product details

SPECIFICATIONS

Working Voltage	110 – 240V AC, 50/60 Hz, single phase for universal use.120W Max.24VDC motorCompatible with Ar gas glovebox
Vibration	Frequency: 300 – 1500 per minuteAmplitude： 16 mm.Time: 1 sec to 6553 sec.Milling time, rest cooling time and speed are programmable via a separate touchscreen control boxAcceleration gravity: ~ 80 G
Material Feed Size	≤ 8mm
Material Output Size	~0.1 – 5 μmMay differ depending on the sample material and processing parameters, such as speed, ball size and quantity
Milling Jars/Balls ( Click the picture to order a spare )	One 20 ml air-tight Zuriconia jar is included with several 5 pcs 5 mm balls and 2 pcs of & 10 mm ballsPlease click the picture below to see how to install the YSZ jar into an aluminum case YSZ jAssemble Video YS YSZ jar sizeFor air-sensitive materials, you can load before milling and unload a sample after milling in the glovebox15 – 50 ml SS, Peek, Si3N4, and zirconia jar are available upon request ( Click the underlined to choose)
Pneumatic Fixture	One pneumatic fixture on the top of the vibration mill to tighten the lid of the jar automatically0.4 Mpa ( 40 bar ) gas pressure is required to drive the pneumatic fixture If using the outside glovebox, you may order a gas compressor at Pic.1 leftIf using an insider glovebox, please use an Ar or N2 gas cylinder
Optional	RS485 PC port and software are available for running multi-device up to 8 unitsRobotic arm and software are available to load and unload mill jars jar automatically
Warranty	One-year limited warranty with lifetime supportThe warranty does not cover consumable parts, such as milling jars and balls
Compliance	CE CertifiedNRTL certification is available at an extra cost
Dimensions & Weight	Net weight：15 kgDimension (mm) : 47L×290W×372H ( Vibration mill ) 360L×290W×60H ( control box)
Reference Video
Application Notes	To reduce the milling jar and ball’s contamination to sample, please fill at least 30% volume sample before milling, then start milling the powder sample at low speed, and let the sample coat on the surface of the jar and ball, then run at the high speed
