Recirculating Chiller CCA-420 DLSB-5/20 DLSB-5/20

In stock

Product originCHINA
Delivery timeWithin 7 days
Supply capacityFactory Direct Supply
Recirculating Chiller is the ideal solution for precise temperature control in various industrial and laboratory applications. Designed for efficiency and reliability, this chiller provides a stable and consistent cooling source for your equipment. With a user-friendly interface, it allows for easy temperature adjustments and monitoring.

  • Estimated delivery time 14-30 days
  • 18 months warranty at Genuine Warranty Center.
  • Whats in the box: charging cable and block
SKU: recirculating-chiller-cca-420-dlsb-5-20-dlsb-5-20
Brand:

Product details

Features:

  • Digital display temperature controller, intelligent temperature control technology.
  • Completely enclosed air-cooled compressor, fast cooling speed.
  • Double-blade circulation pump with large flow rate and high efficiency.

Technical Parameters:

ModelCCA-420DLSB-5/20DLSB-20/40
Temp. DisplayLED display
Tank Volume4L6.8L20L
Matching Reaction Kettle(Steam)1~2L1~5L20L
Tank Material304 Stainless Steel201 Stainless Steel
Tank Size250*130*130mmφ220*180mmφ300*300mm
Temp. Control Accuracy±0.1 °C
Display Temp. Resolution0.1°C
Pump Lift1.5~2.7m4~6m
Circulating Pump Flow8~16L/min20~40L/min
RefrigerantR134AR22
Refrigerating Capacity1550-500W2324-735W6972-2205W
Pressure≤0.4Mpa
Ambient Relative Humidity(60~80%)Ventilation
Instrument Temp. Control Range-20°C~RT-40°C~RT
Optimum Ambient Temp.5~35°C
Unload Min Temp.-20°C-20°C-42°C
Circulation Pump Power100W
Circulating PumpMagnetic pumpFully-closed &No-leaked special pump
Circulating Water Mouth InterfaceOuter diameter 1 mm/Inner diameter7mm
SensorPT100
Coil Diameterφ185mmφ255mm
Opening Sizeφ200mmφ250mm
Power SupplyAC220V±10%, 50/60HZAC220±10%,50y60Hz; AC110±10%, 60HzAC220V±10%, 50/60HZ
ModelCCA-420DLSB-5/20                   DLSB20/40
Secure ProtectionOverload protection,
Overheating protection,
Refrigerator
Delay protector
Leakage,overload circuit breaker,Overload relay
circuit, Refrigerator protection timer, Circulating pump
thermal protector, Refrigerator high-pressure pressure
switch, Temperature control self-diagnosis function
External Size(W*D*H)mm520*250*560485*423*(760+400)590*670*(975+500)
Package Size(W*D*H)mm580*310*560595*435*880725*595*1130
Gross Weight(kg3065122.5
AccessoriesIn and out joint *1
Silicone pipe insulation*2
In and out joint *1,Vertical rod*1,
Thermal insulation pipe*2
Applicable Rotary
Evaporator Model
RE-2010,RE-2000A,RE-2000B,
RE-2000E,RE-52A,RE-52C
RE-5299,RE-201D,RE 100-Pro
RE-301,RE-501RE-1002,ExRE-1002,
RE-2002
