Product details
Features:
- Maximum working pressure up to 6000 psig (413 bar)
- Working temperature from -65℉ to 450℉ (-54℃ to 232℃)
- 2-way, 3-way and angle flow pattern
- Field repairable with seal kit
- Low operating torque
- Panel mountable
- 90 degree actuation
- Bi-directional flow3
- 16 stainless steel, brass and alloy body material
- Variety of end connections
- Color coded handles
Advantages
- Free floating ball design provides seat wear compensation
- Micro-finished ball provides a positive seal
- Straight through flow path for minimum pressure drop
- Adjustable PTFE stem seal can be maintained in-line
- Handle indicates flow direction
- Low operating torques
- Positive handle stops
- 100% factory tested
More Options
- Optional 2 way straight, 2 way angle,3 way
- Optional pneumatic and electric actuation
- Optional live-loaded PTFE stem seals
- Optional non-adjustable O-ring stem seals
- Optional upstream and downstream drain models
- Optional stainless steel and extended handles
